Substrates
Can be applied over solvent-based basecoats and properly prepared paint surfaces in good condition.
Mixing Ratio
2 parts clearcoat to 1 part hardener.
Pot Life
1 hour at 23°C after mixing with hardener.
Spray Gun Tips
Nozzle: 1.3 mm
Conventional: 3.0–3.5 bar (45–50 psi)
HVLP: 2 bar (26–30 psi)
Spray Method
Application viscosity: 16–18 seconds (DIN Cup 4 at 23°C)
Coats: 2 to 3 coats, total film thickness 40–60 μm
Flash-off time between coats: 3–4 minutes at 23°C
Drying Time
At 15°C, the surface is dust-free in 25 minutes and polishable in 60 minutes.
At 23°C, it is dust-free in 20 minutes and polishable in 45 minutes.
At 30°C, it is dust-free in 15 minutes and polishable in 30 minutes.
Shelf Life
2 years in unopened containers when stored in cool, dry conditions.
Health and Safety
Refer to the Material Safety Data Sheet (MSDS) for full information.
Follow all precautionary labels and instructions on the container.
Ensure good ventilation in the working area.
*Suitable for synthetic parts used in a car.
*Fast drying.
*Excellent adhesion.
Mixing ratio:
Plastic Surfacer : Thinner=1 : 1.
Pot life:
1 hour@25℃.
Spray gun& air pressure:
Gravity type: 1.2-1.4mm.
Spray method:
Spray 1-2 layers, the volatilization time of each layer is 5 to 10 minutes.
Drying time:
10-15minutes at 25℃.
Suitable substrates:
Plastic surface.
*Easy to sand.
*Quick drying.
*Excellent adhesion.
Mixing ratio:
2K Primer Surfacer: 4 parts.
Hardener: 1 part.
Thinner: 1-2 parts.
Pot life:
1 hour@25℃.
Spray gun& air pressure:
Gravity type: 1.2-1.4mm.
Suction type: 1.3-1.5mm.
Spray method:
Spray 1-2 layers, the volatilization time of each layer is 5 to 10 minutes.
Drying time:
At 25℃, 20 minutes for touch, 45 minutes for sanding.
Suitable substrates:
OEM paint, steel surface, fiber reinforced plastics, surface of putty.
*Quick drying.
*Good sanding property.
*Providing an active protection against corrosion.
Mixing ratio(by weight):
Epoxy primer: 4 parts.
Hardener: 1 part.
Thinner: 1-2 parts.
Pot life:
4 hours@20℃.
Spray gun& air pressure:
Gravity type: 1.2-1.4mm.
Suction type: 1.3-1.5mm.
Spray method:
Spray 1-2 layers, the volatilization time of each layer is 5 to 10 minutes.
Drying time:
At 25℃, 1 hour for touch, 4 hours for sanding.
Suitable substrates:
Iron and steel, aluminium, sanded galvanized sheet, dryed and sanded old paintings.
*Quick drying.
*Excellent coverage.
*Good sanding property.
Mixing ratio(by weight):
1K Primer Surfacer : Thinner=1 : 1-1.5.
Spray gun& air pressure:
Gravity type: 1.2-1.4mm.
Suction type: 1.3-1.5mm.
Spray method:
Spray 2-3 layer, the volatilization time of each layer is 5 to 10 minutes.
Drying time:
Wet and dry sandable after 30 minutes.
Substrate:
OEM paints, steel, putty, eroded primer, alloy primer.
Non suitable substrate:
Galvanized steel, stainless steel, aluminum, wood.
*Quick, time-saving handling.
*Provides excellent flexibility.
*Has fine homogeneous structure.
*Provides very good adhesion and easy, fast filling with no sagging.
Scrape method:
1.Get the substrate sanded and cleaned.
2. Mix the putty with hardener, the mixing ratio is 100:2-3.
3.Apply smooth film immediately after mixing, avoiding air entrapment.
Port life:
5-8 minutes.
Sanding time:
30-40minutes@25℃.
Sanding:
Coarse sand P80-P120, Final sand P180-P240.
Substrate:
Bare steel, galvanized steel, primer, aluminium and OEM paints.
Unapplicable substrate:
Corroded steel, plastic.
*Quick, time-saving handling.
*Provides excellent flexibility.
*Has fine homogeneous structure.
*Provides very good adhesion and easy, fast filling with no sagging.
Scrape method:
1.Get the substrate sanded and cleaned.
2. Mix the putty with hardener, the mixing ratio is 100:2-3.
3.Apply smooth film immediately after mixing, avoiding air entrapment.
Port life:
5-8 minutes.
Sanding time:
30-40minutes@25℃.
Sanding:
Coarse sand P80-P120, Final sand P180-P240.
Substrate:
Steel, primer and OEM paints.
Unapplicable substrate:
Corroded steel, galvanized steel.
*Quick, time-saving handling.
*Provides excellent flexibility.
*Has fine homogeneous structure.
*Provides very good adhesion and easy, fast filling with no sagging.
Scrape method:
1.Get the substrate sanded and cleaned.
2. Mix the putty with hardener, the mixing ratio is 100:2-3.
3.Apply smooth film immediately after mixing, avoiding air entrapment.
Port life:
9-13 minutes.
Sanding time:
30-40minutes@25℃.
Sanding:
Coarse sand P80-P120, Final sand P180-P240.
Substrate:
Steel, primer and old paint film.
Unapplicable substrate:
Corroded steel, galvanized steel.
